Railway rail is referred to as track, rail, track, etc. It is used on the railway, and in cooperation with the switch, so that the train can move without turning.
The track is usually composed of two parallel rail, rail fixed on the rail pillow, sleeper under the road ballast, also including roadbed, rail connection parts
Product name
Standard
AiSi, ASTM, bs, DIN, GB, JIS
Grade
50Mn/U71Mn
Rail Heigth
140mm
Bottom Width
114mm
Web Thickness
14.5mm
Head Width
70mm
Length
12.5-25m
Place of Origin
China
Shandong
Brand Name
Angang
Type
Heavy Rail
Application
Railway Rail
Weight
44.653kg/m
Secondary Or Not
Non-secondary
Bolt Hole Diameter
Standard
Tolerance
±1%
Delivery Time
22-30 days
